WiFi 4K HDMI Encoder(Real Time Local Loop Output)

$399.90 available: In Stock
Quick Overview:The HEV-10W is a compact, yet professional wireless H.265 HDMI Video Encoder that enables high-quality, low-latency content streaming and display. It supports a maximum of 4K@60Hz input and can stream to popular services such as YouTube Live, Facebook Live, Twitch or to a custom-specified RTMP server at up to 1080p via Ethernet, Wi-Fi and mobile hotspot connection. The HEV-10W also provides a zero-latency, up to 4K@60Hz loop-out that connects to a local display for live monitoring.

DDMALL Wireless H.265 HDMI Video Encoder with Local HDMI Loop Out

Compact, Powerful and Reliable

The HEV-10W is a compact, yet professional wireless H.265 HDMI Video Encoder that enables high-quality, low-latency content streaming and display. It supports a maximum of 4K@60Hz input and can stream to popular services such as YouTube Live, Facebook Live, Twitch or to a custom-specified RTMP server at up to 1080p via Ethernet, Wi-Fi and mobile hotspot connection. The HEV-10W also provides a zero-latency, up to 4K@60Hz loop-out that connects to a local display for live monitoring.


Key Features

• Supports H.265/HEVC and H.264/AVC compression
• Supports up to 4K@60Hz HDMI input
• Zero-latency HDMI loop-out, up to 4K@60Hz
• Stream at up to 1080P
• Controlled with user-friendly web UI
• Supports 24/7 working
• Power by universal USB connection. Ideal for portable streaming events • Supports multiple streaming protocols, including RTMP, RTMPS, RTSP, TS, RTP, UDP, Multicast and Unicast


DDMALL

DDMALL is a professional manufacturer and designer of hardware video encoders & decoders with over 20 years’ experience. We are specialists in this niche video over IP industry and supply to a range of markets worldwide. Our products are set apart from the competition in terms of reliability, performance, integration and compatibility.

The DDMALL Advantage

• Leading Technologies
• 20+ Years' Experience
• Strong R&D Capabilities
• ISO Certification
• OEM & ODM Specialist






Specifications

• Video Codec: H.265/HEVC, H.264/AVC
• Supported Streaming Protocol: RTMP, RTMPS, RTSP, TS, RTP over UDP, RTP over TCP, Multicast, Unicast, TCP and UDP.
• Supported Input Resolutions: 4096×2160p@60/30Hz, 3840×2160p@60/30Hz, 1920×1080p@60Hz/50Hz/30Hz, 1920×1080i@60Hz/50Hz, 1280×720p@60Hz/50Hz/30Hz
• Supported Output Resolutions: 1080p@30Hz, 720p@60Hz/30Hz, 960×720@60Hz, 960×540@60Hz, 640×480@60Hz, 360×200@60Hz
• Adjustable Video Bitrate: 128Kpbs~16Mpbs (CBR/VBR/AVBR/FixQP Controlling Mode) Manual bitrate supported
• TTL value is adjustable
• Audio Codec: AAC, G.711u
• Key Frame Interval (GOP) is tunable
• Compression profile: BaseLine, Main, High
• Stable and energy-efficient, supports 7 x 24h working time
• Supports remote management in WAN (WEB)
• Ideal for many applications, such as church live streaming, online broadcasting, UAV/Drone applications, IPTV/NVR systems and more
• Supports most internet video platforms including YouTube, Facebook, Ustream, Livestream, Twitch, Meridix, Streamspot, Dacast, Tikilive, Netrmedi, etc.


What's in the Box

• 1×HEV-10W Encoder, 1×USB Power Cable, 1×Wi-Fi Antenna, 1×User Manual









●【Compact & Reliable】This compact video encoder is built for easy, live video and audio streaming from any HDMI sources to online services like YouTube, Facebook , Twitch or other content delivery services and content management systems over Wi-Fi Network, mobile hotspot or wired Ethernet. It has both H.264/AVC and H.265/HEVC in the same unit. Supports multiple streaming protocols, including RTMP, RTMPS, RTSP, RTP, UDP, TS, Unicast and Multicast.

●【4K Real Time Local Loop Out】This compact encoder supports a maximum of one 4K@60Hz video input and one 4K@60Hz HDMI loop out for external display. There is no delay between HDMI input and the local output, this means you can monitor your live video in real time to engage with your audience.

●【Easy to Use】It is controlled via web-based user interface, which you can access through its IP address and configure everything, e.g. resolutions, bitrates, stream URL and more through a common browser on your mobile phone, PC and tablet, with no external software installation needed. It comes with a multi-function button that allows you to start and stop streaming simply by pressing the button, no need to reconfigure the device constantly.

●【USB-Powered】This compact encoder features low power consumption, this makes it ideally suited for 24*7 live streaming events. It can be powered from any basic USB connections, no proprietary AC power adapter required. Forget about bulky power adapter, we’ve got you covered. 【What’s in the Package】1× HDMI Video Encoder, 1×USB Power Cable, 1×User Manual.

●【Buy with Confidence】At DDMALL, we pride ourselves on providing innovative and high quality A/V products to our customers. We work directly with our users to create a product we all love. We believe in our products, that's why we are confident in offering 3-Year worry-free Manufacturer Warranty and free, lifetime, 24/7 technical support. We also provide free features customization services to every customer. If you have any questions or concerns, please do not hesitate to contact us.


   •  Video Codec: H.265/HEVC, H.264/AVC

   •  Supported Streaming Protocol: RTMP, RTMPS, RTSP, TS, RTP over UDP, RTP over TCP, Multicast, Unicast, TCP and UDP

   •  Supported Input Resolutions: 4096×2160p@60/30Hz, 3840×2160p@60/30Hz, 1920×1080p@60Hz/50Hz/30Hz, 1920×1080i@60Hz/50Hz, 1280×720p@60Hz/50Hz/30Hz

   •  Supported Output Resolutions: 1080p@30Hz, 720p@60Hz/30Hz, 960×720@60Hz, 960×540@60Hz, 640×480@60Hz, 360×200@60Hz

   •  Adjustable Video Bitrate: 128Kpbs~16Mpbs (CBR/VBR/AVBR/FixQP Controlling Mode) Manual bitrate supported

   •  TTL value is adjustable

   •  Audio Codec: AAC, G.711u

   •  Key Frame Interval (GOP) is tunable

   •  Compression profile: BaseLine, Main, High

   •  Stable and energy-efficient, supports 7 x 24h working time

   •  Supports remote management in WAN (WEB)

   •  Ideal for many applications, such as church live streaming, online broadcasting, UAV/Drone applications, IPTV/NVR systems and more

   •  Supports most internet video platforms including YouTube, Facebook, Ustream, Livestream, Twitch, Meridix, Streamspot, Dacast, Tikilive, Netrmedi, etc
